ER5183
AWS A5.10 ER5183
EN ISO 18273 S Al 5183 (AlMg4.5Mn0.7(A)）
Description：
A high magnesium aluminium welding wire is mainly used where higher tensile strength is required. If the tensile strength requirement is 40ksi (276MPa) or higher, used on 5083 or 5654 base metal. Used in marine and low temperature industries, or high strength aluminium structures.
Diameters:
0.8mm, 0.9mm, 1.0mm, 1.2mm, 1.6mm.
Typical Mechanical Properties:
Tensile strength(MPa): | 290 |
Yield stress(MPa): | 140 |
Elongation(%): | 26 |
Impact values(≥47J/+20℃): | 30 |
Typical Chemical Properties:
Si | Fe | Cu | Mn | Mg |
0.1 | 0.3 | 0.05 | 0.6-1.0 | 4.7-5.2 |
Cr | Zn | Be | Ti | Al |
0.06-0.14 | 0.10 | 0.0008 | 0.02-0.08 | Allowance |
Welding Current:(DC+)
Dia:(mm) | 0.8 | 0.9 | 1.0 | 1.2 | 1.6 |
Current/A | 60-170 | 60-170 | 90-210 | 140-260 | 190-350 |
Voltage/V | 13-24 | 13-24 | 15-26 | 20-29 | 25-30 |
Note:
1.Rusty, oil stains, water and other impurity on the weld parts must be cleaned before welding.
2. Shield Gas:100%Ar or 75%Ar+25%He or 50%Ar+50%He
3. In order to get good welding bead, weld on thick plate should be preheat 100-200℃ before welding.
4. Tig rods ER5183 1.6mm, 2.0mm, 2.4mm, 3.2mm available
